Boston Whaler 190 Montauk

Electrical & Controls:

• 12-V receptacle
• Electrical switch panel with circuit breaker protection
• Smart Craft digital gauges
• Binnacle control
• Compass
• Classic style navigation lights
• Vessel view mobile
• Battery box with hold-down strap in console

Seating & Storage:

• Reversible pilot seat with locking backrest and storage underneath
• Drink holders (4)
• Grab rail – welded stainless steel
• Partitioned storage at top of helm
• Rod holders (4)
• Forward fishbox / storage with overboard drain
• Bow locker with fiberglass cover and overboard drain
• Aft cockpit storage with fiberglass covers (2)
• Fuel tank (60 gallons)

Structural & Exterior:

• 19” interior freeboard
• 8″ stainless steel cleats (3)
• Boarding steps – molded in port and starboard
• Heavy-duty rub rail
• Bow rail – welded stainless steel
• Side rails – welded stainless steel
• Lifting eyes – bow and stern
• Self-bailing cockpit sole
• Disc brakes
• Tie-downs
• Torsion axle
• Trailer jack
• Winch with nylon strap
• Spare tire with radial tires

Engine:

• 115 EXLPT EFI Command Thrust FourStroke Mercury® engine
• Hydraulic steering
• Propeller – stainless steel

Safety Features:

• Fire extinguisher pocket
• Electric horn
• Bilge pump with float switch

Additional Features:

• Acrylic windshield
• 60 gallons fuel tank
• All hardware 316-L stainless steel
• All rails welded 316-L stainless steel

Engine Options:

Mercury Engine Options:

• Mercury 150 XL EFI 4 STROKE, 150HP
  • Features: 66.5-gallon integrated fuel tank, analog instrumentation, stainless steel propeller, dual battery trays & wiring, Smart Craft digital gauges, vessel view mobile, hydraulic steering, galvanized tandem axle trailer with swing tongue, radial tires, spare tire & disc brakes.
• Boat Only No Engine

Options:

Seating and Table Options:

• Fore and Aft Seating Package (Aft seats (port and starboard) with plug-in backrest & bow cushion)

Canvas and Cover Options:

• Combination Reversible Pilot Seat Console Cover
• Suntop with Boot (Stainless steel fittings, must select canvas color above)

Electronics and Navigation:

• 7” Simrad NSX Electronics/Navigation Package (GPS, Chart plotter, Fishfinder, Active Imaging 3 in 1 Transom Mount Transducer, C-Map® Discover™ X Chart Card)
• 9” Simrad NSX Electronics/Navigation Package (GPS, Chart plotter, Fishfinder, Active Imaging 3 in 1 Transom Mount Transducer, C-Map® Discover™ X Chart Card)
• Stereo JL Audio (MM50 AM/FM with waterproof speakers (4), MP3/USB inputs, and Bluetooth compatible)
• VHF Radio (Simrad RS20S VHF Radio)

Hardware & Accessories:

• Black Rub Rail with Stainless Steel Insert (std is black/w black insert)
• Bow Tow Eye
• Complete Rail Package (Bow rail (high), low profile bow rail, aft rail (high) & low profile stern rail)

Safety & Security:

• First Mate Safety & Security System FOB Kit (Includes additional Man Overboard (MOB) FOB’s for additional passengers (Qty 4))
• First Mate Safety & Security System Single Engine (Includes Captain FOB and 3 passenger FOB’s)

Fishing & Livewell:

• Fishing Package (72-quart cooler with cushion, backrest, console mounted rod holders (4) and tackle drawers (2))
• Livewell with Blue Interior (Located at Reversible Pilot Seat)

Structural Features:

• Low Profile Bow Rail (Replaces standard high Bow Rail)
• Split Bow Rail (Replaces standard high bow rail)
• Teak Package (Teak boarding steps and teak flooring on swim ladder)
• Tow Arch Powder Coated (Must choose black or white)
• T-Top Powder Coated (5 rod holders and storage bag, must select canvas color above)

Additional Features:

• Upgraded Console Cooler (Yeti, must select fishing package)
• White Rub Rail with Stainless Steel Insert (std is black/w black insert)

Charts & Certification:

• C-Map Discover X Chart Card (Multiple regions available)
• Canadian Certification
• CE Certification
• Australian Certification

Freight and Prep Options:

• Inland Freight: (US & Canada)
• Inland Freight – International Only
• Export Packing on Cradle
• Marine Insurance
• Container Packing Fee (Applies with or without trailer)

Capacity:

• Persons Capacity: 8
• Fuel Capacity: 60 gallons (227 L)
• Maximum Weight Capacity: 2,500 lbs (1,134 kg)
• Swamped Capacity: 4,000 lbs (1,814 kg)

Dimensions:

• Length Overall (L.O.A.): 19’ 4” (5.89 m)
• Beam: 8’ (2.43 m)
• Bridge Clearance (no top): 60” (1.52 m)
• Bridge Clearance (with suntop): 126” (3.2 m)
• Bridge Clearance (with T-Top): 87” (2.20 m)
• Bridge Clearance (on trailer with T-Top): 90” (2.28 m)
• Draft: 13” (0.33 m)
• Transom Height: 25” (0.63 m)

Engine Options:

• Maximum Horsepower: 150 HP (112 kW)
• Maximum Engine Weight: 530 lbs (240 kg)
• Minimum Horsepower: 115 HP (86 kW)

Weight:

• Weight (dry, no engine): 2,000 lbs. (907 kg)
• Weight (with engine, fuel, and water): 2,769 lbs (1,256 kg)
